| Product Attribute | Attribute Value |
|---|---|
| Air Flow | 883 CFM (25004 L/Min.) |
| Approximate Thickness | 4.6 In. (117 mm) |
| Bearing Type | Ball |
| Configuration | Square |
| Current Rating | 1.25 A |
| Dimensions | 11.8 x 11.8 x 4.55 In. (300 x 300 x 115.5 mm) |
| Fan Type | AC |
| Frequency | 50;60 Hz |
| Material | Plastic |
| Maximum Operating Temperature | 70/50 C |
| Minimum Operating Temperature | -25/-25 C |
| Noise Level | 67/68 dBA |
| Power Rating | 285 W |
| Primary Type | Fan |
| Rotation | CW |
| Size | 11.8 x 4.55 (300 x 115.5) In. (mm) |
| Size, Approximate | 11.8 x 11.8 In. (300 x 300 mm) |
| Speed | 2450 RPM |
| Termination | Terminals |
| Type | Square |
| Voltage Rating | 230 VAC |
Overview
ebm-papst Centrifugal Fans and Blowers - Backward Curved Blades
ebm-papst centrifugal fans and blowers featuring backward curved blades are an ideal solution to a wide range of application requirements and are ideally suited for intake suction use. Additionally, ebm-papst centrifugal fans and blowers, specifically those used for intake suction using backward curved blades, do not require a scroll housing - increasing ease of use and versatility.
