| Product Attribute | Attribute Value |
|---|---|
| Air Flow | 212 CFM (6003 L/Min.) |
| Approximate Thickness | 1.5 In. (38 mm) |
| Bearing Type | Ball |
| Configuration | Obround (Flat Sides/Rounded Ends) |
| Current Rating | 0.19 A |
| Dimensions | 6.8 x 5.9 x 1.5 In. (172 x 150 x 38 mm) |
| Fan Type | AC |
| Frequency | 50;60 Hz |
| Material | Diecast Aluminum |
| Maximum Operating Temperature | 70 C |
| Minimum Operating Temperature | -10 C |
| Noise Level | 52/56 dBA |
| Power Rating | 35 W |
| Primary Type | Fan |
| Rotation | CW |
| Series | |
| Size | 6.8 x 5.9 x 1.5 (172 x 150 x 38) In. (mm) |
| Size, Approximate | 6.8 x 5.9 In. (172 x 150 mm) |
| Speed | 3200 RPM |
| Temperature Range | -10 to 70 C |
| Termination | Terminals |
| Type | Obround (Flat Sides/Rounded Ends) |
| Voltage Rating | 230 VAC |
| Weight | 26 Oz. |
Overview
Features:
- Longer Life
- Higher Temperature Extremes
- Lower Noise Over Time
- Maximum Shock and Vibration Resistance
